Aquablend: eSQX - Touch-Free - On Demand Sensor Point-of-Use Thermostatic Wall Mixer - Front of Wall Component - 12V Mains - 200mm Spout

Product Code: ATWMC1L5

Download data sheet Download install guide

Product description

Aquablend eSQX is Australia’s first and most technically advanced touch-free thermostatic mixer solution. Designed to deliver touch-free pre-mixed warm water for enhanced infection control and cross-contamination prevention. The solution includes an infra-red sensor located above the outlet, designed for clinical hand to elbow washing for surgical scrub, and Type A and Type B wash stations.

Key Selling Points

On Demand Sensor - place hand in front of sensor to turn on, valve stays open without hand remaining in the sensor range. Place hand in front of sensor again to turn off
Low voltage 12V mains power supply
200mm spout
Flush cycle stagnation management to reduce risk of bacterial growth, usage monitoring and other function settings are adjustable via Oras App and Bluetooth connectivity
Effective reduction of Legionella ris
AHFG Type A and B healthcare basin compatibility
Compatible with Smartflow Monitoring System for TMV monitoring and reporting
Smart, durable easy-clean chrome surfaces
Smooth bore tubular spout designed to minimise bacteria growth
IP67 rated connections
Faceplate can be removed to access integral isolation/check valves, strainers and inspection ports
