Ifo Sign Junior Toilet – S Trap

Product Information

One-piece free standing junior toilet. Suitable for child care or infant school applications. AS1428.1-2009 Part 3 compliant. Seat included.

  • Free standing WC supplied with a dedicated toilet seat
  • Seamless cistern for added infection control
  • Ergonomically designed to suit young children between 3 & 6 years old
  • Finished installed height including seat = 315mm
  • Cistern bolted onto pan for enhanced back support
  • Fully glazed on back and inside rim to avoid bacteria growth

Inlet & Outlet

Inlet Connection 1/2" BSP Male (DN15mm)Bottom inlet on cistern, on the right hand side looking from the front of pan
Outlet Connection 100mm Pan Collar (Pan Collar Not Supplied)

Dimension

Pan load rating 400kg

Water Supply

Water Supply Pressure Recommended Maximum 500 kPa
Product Code Description PRIMARY FLOW RATE AVG FLUSH FLOW RATE MIN FLUSH FLOW RATE FINISH
IFO6820 Ifo Sign Junior Toilet – S Trap 4.5L/minute 3.3 3 Vitreous China Add to spec
IFO99418 Ifo Sign Junior Toilet – S Trap – Junior Sign Toilet Seat L/minute Add to spec
